Monitor Arm and Keyboard
5000 Monitor Arm and Keyboard
Frame Electronics 4000/5000 Series

Please select the part you need from the drawing and drop down list:


  • AN-011: Monitor-Keyboard Mount
  • HDW-90039: Hex socket head cap screw M6x1.00 x 20
  • HDW-90067: Socket button head cap screw 1/4-20 x 0.75
  • HDW-90069: Hex socket head cap screw M4x0.70 x 16
  • PN-050: Ergotron Raiser Mount
  • PN-051: Ergotron Extrusion Mount
  • PN-2097: 1/4-20 T-Nut (10mm)
  • PN-2099: M5 T-Nut (8mm)
  • PN-2269: 30x60 End Cap
  • PN-2356: Ergotron Wall Mount Arm
  • PN-2357: Mini Keyboard
  • PN-2375: ELO 19.5" Monitor

Once you find the part(s) you need, please submit via our request@rothgreaves.com email or give us a call (1-952-404-2604). Please include your Machines' serial number.
